FUEL VALVE KIT YFM 660 F Grizzly 4x4 02-08, Fuel Star FS101-0041 YAMAHA ATV, TAPE / PETCOCK / CLIPS / PIPES / BOLTS

The Fuel Star FS101-0041 Fuel Valve Kit is a complete replacement petcock assembly designed for 2002–2008 Yamaha YFM660F Grizzly 4x4 models, including standard, Hunter, Special, Ducks Unlimited, and Limited Editions. This kit includes all essential components for installation and matches OEM specifications.

Features

• Complete replacement fuel petcock assembly

• Includes gasket, fuel line, clamps, mounting hardware, knob, and line wrap

• Direct-fit design for specified Yamaha ATV models

• Sold individually

Specifications

• (1) Fuel petcock

• (1) Gasket

• (1) Rubber hose

• (1) Black plastic knob

• (1) Fuel line wrap

• (2) 6mm-1.00 x 15mm flange head bolts

• (1) 4mm-.7 x 16mm flat head bolt

• (2) Hose clamps

Cross-Reference OEM Part Numbers

• 5KM-24500-01-00 (Fuel Cock Assy)

• 5KM-24500-10-00 (Fuel Cock Assy)

• 3AC-24523-00-00 (Valve Packing)

• 3AJ-24534-01-00 (Seal, Cock)

• 98507-03014-00 (Screw, Pan Head)

• 4X8-24512-00-00 (O-Ring)

• 90149-06011-00 (Screw)

• 5GH-24524-00-00 (Lever, Cock)

• 1NS-F4524-00-00 (Lever, Cock)

• 98707-04018-00 (Screw, Flat Head)

• 5KM-24311-10-00 (Pipe, Fuel 1)

• 5KM-24327-02-00 (Protector, Pipe)

• 90467-12053-00 (Clip)

• 90467-11044-00 (Clip)

Vehicle Fitments

• 2002 Yamaha YFM660F Grizzly 4x4

• 2003 Yamaha YFM660F Grizzly 4x4

• 2004 Yamaha YFM660F Grizzly 4x4

• 2002 Yamaha YFM660FH Grizzly 4x4 Hunter Edition

• 2003 Yamaha YFM660FH-H Grizzly 4x4 Hardwoods Hunter Edition

• 2003 Yamaha YFM660FH-WL Grizzly 4x4 Wetlands Hunter Edition

• 2004 Yamaha YFM660FH Grizzly 4x4 Hardwoods Hunter Edition

• 2004 Yamaha YFM660FH-WL Grizzly 4x4 Wetlands Hunter Edition

• 2003 Yamaha YFM660F-GY Grizzly 4x4 Limited Edition

• 2004 Yamaha YFM660FLE Grizzly 4x4 Limited Edition

• 2005 Yamaha YFM660FLE Grizzly 4x4 Limited Edition

• 2005 Yamaha YFM660FA Grizzly 4x4

• 2006 Yamaha YFM660FA Grizzly 4x4

• 2007 Yamaha YFM660FA Grizzly 4x4

• 2008 Yamaha YFM660FA Grizzly 4x4

• 2005 Yamaha YFM660FAHW Grizzly 4x4 Wetlands Hunter Edition

• 2006 Yamaha YFM660FAHD Grizzly 4x4 Ducks Unlimited Edition

• 2005 Yamaha YFM660FASE Grizzly 4x4 Special Edition

• 2006 Yamaha YFM660FASE Grizzly 4x4 Special Edition

• 2007 Yamaha YFM660FG Grizzly 4x4

• 2008 Yamaha YFM660FG Grizzly 4x4

• 2007 Yamaha YFM660FGH Grizzly 4x4 Hunter Edition

• 2008 Yamaha YFM660FGH Grizzly 4x4 Hunter Edition
