FUEL VALVE KIT YFM400/450 03-07, Fuel Star FS101-0051 YAMAHA ATV, TAPE / PETCOCK / CLIPS / PIPES / BOLTS

The FS101-0051 Fuel Star Fuel Valve Kit is a complete replacement petcock assembly engineered for compatibility with various Yamaha Kodiak and Grizzly 4x4 ATVs manufactured between 2003 and 2007. Designed to meet OEM specifications, this kit includes all components necessary for installation.

Features

• Complete replacement fuel petcock assembly

• Sold each

Specifications

• (1) Fuel valve assembly

• (1) Rubber fuel line

• (2) Fuel line clamps

• (2) 6mm-1.00 x 15mm Phillips washer head bolts

• (2) Mounting spacers

• (1) Plastic on/off fuel knob

• (1) 4mm-.70 x 15mm tapered Phillips head screw

Cross-Reference OEM Part Numbers

• 5GH-24500-00-00 (Fuel Cock Assy)

• 5GH-24500-10-00 (Fuel Cock Assy)

• 4X8-24512-00-00 (O-Ring)

• 98507-03014-00 (Screw, Pan Head)

• 3AJ-24534-00-00 (Seal, Cock)

• 3AJ-24534-01-00 (Seal, Cock)

• 3AJ-24523-00-00 (Valve Packing)

• 3AC-24523-00-00 (Valve Packing)

• 5GH-24524-00-00 (Lever, Cock)

• 1NS-F4524-00-00 (Lever, Cock)

• 98707-04018-00 (Screw, Flat Head)

• 90202-05193-00 (Washer, Plate)

• 90202-05187-00 (Washer, Plate)

• 90149-06011-00 (Screw)

• 5ND-F4311-00-00 (Pipe, Fuel 1 (YMUS))

• 3C2-F4311-00-00 (Pipe, Fuel 1 (YMUS))

• 90467-10008-00 (Clip)

• 90467-100A1-00 (Clip)

Vehicle Fitments

• 2003 Yamaha YFM400FA Kodiak 4x4 Ultramatic

• 2004 Yamaha YFM400FA Kodiak 4x4 Ultramatic

• 2005 Yamaha YFM400FA Kodiak 4x4 Ultramatic

• 2006 Yamaha YFM400FA Kodiak 4x4 Ultramatic

• 2003 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Hunter Edition

• 2004 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Hunter Edition

• 2005 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Hunter Edition

• 2006 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Hunter Edition

• 2007 Yamaha YFM400FG Grizzly 4x4

• 2007 Yamaha YFM400FGH Grizzly 4x4 Hunter Edition

• 2003 Yamaha YFM450FA Kodiak 4x4

• 2004 Yamaha YFM450FA Kodiak 4x4

• 2005 Yamaha YFM450FA Kodiak 4x4

• 2006 Yamaha YFM450FA Kodiak 4x4

• 2003 Yamaha YFM450FAH Kodiak 4x4 Hunter Edition

• 2004 Yamaha YFM450FAH Kodiak 4x4 Hunter Edition

• 2005 Yamaha YFM450FAH Kodiak 4x4 Hunter Edition

• 2006 Yamaha YFM450FAH Kodiak 4x4 Hunter Edition

• 2005 Yamaha YFM450FSE Kodiak 4x4 Special Edition

• 2006 Yamaha YFM450FSE Kodiak 4x4 Special Edition
