FUEL VALVE KIT YFM400FA Kodiak 00-02, Fuel Star FS101-0052 YAMAHA ATV, TAPE / PETCOCK / CLIPS / PIPES / BOLTS

The FS101-0052 Fuel Star Fuel Valve Kit is a complete replacement petcock assembly designed for Yamaha YFM400FA Kodiak 4x4 ATVs and select Big Bear models from 2000 to 2002. This kit includes all necessary components for installation and is built to match original equipment specifications.

Features

• Complete replacement fuel petcock assembly

• Sold each

Specifications

• (1) Fuel valve assembly

• (1) Rubber fuel line

• (2) Fuel line clamps

• (2) 6mm-1.00 x 15mm Phillips washer head bolts

• (2) Mounting spacers

• (1) Plastic on/off fuel knob

• (1) 4mm-.70 x 15mm tapered Phillips head screw

Cross-Reference OEM Part Numbers

• 5GH-24500-00-00 (Fuel Cock Assy)

• 5GH-24500-10-00 (Fuel Cock Assy)

• 4X8-24512-00-00 (O-Ring)

• 98507-03014-00 (Screw, Pan Head)

• 3AJ-24534-00-00 (Seal, Cock)

• 3AJ-24534-01-00 (Seal, Cock)

• 3AJ-24523-00-00 (Valve Packing)

• 3AC-24523-00-00 (Valve Packing)

• 5GH-24524-00-00 (Lever, Cock)

• 1NS-F4524-00-00 (Lever, Cock)

• 98707-04018-00 (Screw, Flat Head)

• 90202-05193-00 (Washer, Plate)

• 90202-05187-00 (Washer, Plate)

• 90149-06011-00 (Screw)

• 5GH-24311-00-00 (Pipe, Fuel 1)

• 90467-10008-00 (Clip)

• 90467-100A1-00 (Clip)

Vehicle Fitments

• 2000 Yamaha YFM400F Big Bear 4x4

• 2000 Yamaha YFM400FA Kodiak 4x4 Ultramatic

• 2001 Yamaha YFM400FA Kodiak 4x4 Ultramatic

• 2002 Yamaha YFM400FA Kodiak 4x4 Ultramatic

• 2000 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Hunter Edition

• 2001 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Hunter Edition

• 2002 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Hunter Edition

• 2000 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Realtree X-Tra

• 2001 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Realtree X-Tra

• 2002 Yamaha YFM400FAH Kodiak 4x4 Ultramatic Realtree X-Tra
