YAMAHA
XT225 1992 - 2006,
YFB250 Timberwolf 2x4 1992 - 1997,
YFB250FW Timberwolf 4x4 1994 - 2000,
YFM225 Moto-4 1986 - 1988,
YFM250 Bear Tracker 1999 - 2004,
YFM250 Moto-4 1989 - 1991,
YFM450F Kodiak Auto 4x4 1983 - 1989,
YFU1TW Pro Hauler Turf 1989,
YFU1W Pro Hauler 1989,
YTM225 Tri-Moto 1983 - 1986,
CONNECTING CONROD ROD REBUILD KIT.
- OE replacement connecting rods.
- Certified Chorme alloy steel provides superior strength.
- Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
- Thrust washers are manufactured from bronze phosphor and are silver coated.
- Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
- Fully Compatible with after market and OE crankshafts.
- Material SNCM220,
|
SIZE
|
MM
|
|
Centre 2 Centre
|
100.50
|
|
Small End Bearing
|
None
|
|
Small End Bore Ø
|
16
|
|
Small End Width
|
20
|
|
Big End Bearing
|
30x37x20
|
|
Big End Bore Ø
|
37
|
|
Big End Width
|
20
|
|
Big End Pin Ø
|
30
|
|
Big End Pin Length
|
54.70
|
|
Washer Thickness
|
None
|
Cross reference numbers ONLY.
PROX 03.2325, VESRAH VA-2005,
2006 Yamaha XT225 2005 Yamaha XT225 2004 Yamaha XT225 2003 Yamaha XT225 2002 Yamaha XT225 2001 Yamaha XT225
