CYLINDER KIT 92.00mm 96-12 POLARIS RANGER SPORTSMAN 500 3085526 3090293

POLARIS FITMENTS:

• Scrambler 500 97-10
• Sportsman 500 96-10
• Sportsman 570 08-08
• Sportsman X2 500 06-09
• Worker 500 99-01
• Xplorer 500 97-97
• ATP 500 04-05
• Big-Boss 500 98-98
• Magnum 425 99-99
• Magnum 500 99-03
• Ranger 425 01-02,04-04
• Ranger 500 99-00,05-10
• RANGER 500 1999-2012
• 2008 RANGER 500 2X4 (R08RB50AA)
• 2008 RANGER 500 2X4 CARB ISRAEL MILITARY (M08RB50AA)
• 2008 RANGER 500 EFI 4X4 (R08RH50AF/AR/AT)
• 2007 RANGER 500 4X4 (R07RB50AA/RH50AA)
• 2007 RANGER 500 EFI 4X4 (R07RH50AF/AR/AT)
• 2006 RANGER 500 4X4 (R06RB50AA)
• 2006 RANGER 500 EFI 4X4 (R06RD50AC)

Comes with new tensioner!!

Cylinder, Piston & Gasket TOP QUALITY OEM REPLACEMENT.

Replaces Existing Cylinder Assembly, Just replace and ride again. This is a brand new cylinder kit for your Polaris 500 engine. The kit includes a brand new standard-sized cylinder, piston kit, and gasket kit. All parts are brand new and built to factory Polaris tolerances. The kits are ready to bolt on your ATV or UTV with no machining or modifications required. All parts are shipped in a custom-made foam-molded package, ensuring your parts arrive safe and ready to use without the chance of shipping damages.

Part No. 56-K213.KIT.STD

Cross-reference numbers:

• 3085369
• 3086811
• 3085526
• 3085634
• GASKET HEAD 3085371
• GASKET (ROCKER COVER) 3085074
• GASKET-CYLINDER 3085370
• 3085534 CLIP(2)
• 3085534 SET PISTON, STANDARD 3085866
• 3087170 SET PISTON, RING, STANDARD 3085379
• 3087224 3084845
• 9999999 GASKET PLUG 3084920
• SPRING-TENSIONER 3086839
• 3086814 TENSIONER ASM 3086813
• GASKET TENSIONER 3084922

Assemblies where 3086811 is used:

• 1999 RANGER (A99RF50AA) - Cylinder
• 2000 500 MAGNUM 4X4, HDS (A00CD50FA) - Cylinder A00cd50fb
• 2000 500 MAGNUM 4X4, HDS II (A00CD50FB) - Cylinder
• 2000 INT'L BIG BOSS (A00CL50DA) - Cylinder A00cl50aa
• 2000 MAGNUM 500 (A00CD50AA) - Cylinder A00cd50fb
• 2000 MAGNUM 500 EB (A00CD50AB) - Cylinder A00cd50fb
• 2000 SCRAMBLER 500 (A00BG50AA) - Cylinder
• 2000 SPORTSMAN 500 (A00CH50AA) - Cylinder A00ch50ak
• 2000 SPORTSMAN 500 (A00CH50AB) - Cylinder A00ch50ak
• 2000 SPORTSMAN 500 (A00CH50AE) - Cylinder A00ch50ak
• 2000 SPORTSMAN 500 (A00CH50AF) - Cylinder A00ch50ak
• 2000 SPORTSMAN 500 (A00CH50AH) - Cylinder A00ch50ak
• 2000 SPORTSMAN 500 (A00CH50AK) - Cylinder
• 2000 SPORTSMAN 500 (A00CH50AL) - Cylinder A00ch50ak
• 2000 SPORTSMAN 500 (A00CH50EB) - Cylinder A00ch50ak
• 2000 SPORTSMAN 500 RSE (A00CH50AC) - Cylinder A00ch50ak
• 2000 SPORTSMAN 500 RSE (A00CH50AJ) - Cylinder A00ch50ak
• 2000 SPORTSMAN 6X6 (A00CL50AA) - Cylinder
• 2001 500 MAGNUM 500 HDS (A01CD50FB) - Cylinder A01cd50aa
• 2001 INT'L BIG BOSS 6X6 (A01CL50DA) - Cylinder A01cl50aa
• 2001 MAGNUM 500 (A01CD50AA) - Cylinder
• 2001 SCRAMBLER 500 2X4 (A01BA50AA) - Cylinder
• 2001 SCRAMBLER 500 2X4 (A01BA50AB) - Cylinder A01ba50aa
• 2001 SCRAMBLER 500 4X4 (A01BG50AA) - Cylinder A01bg50(Ab) (4963766376D001)
• 2001 SCRAMBLER 500 4X4 (A01BG50AB) - Cylinder A01bg50(Ab) (4963766376D001)
• 2001 SPORTSMAN 500 DUSE (A01CH50AD) - Cylinder
• 2001 SPORTSMAN 500 DUSE HO (A01CH50AF) - Cylinder A01ch50eb
• 2001 SPORTSMAN 500 HO (A01CH50AA) - Cylinder A01ch50eb
• 2001 SPORTSMAN 500 HO (A01CH50AB) - Cylinder A01ch50eb
• 2001 SPORTSMAN 500 HO (A01CH50AE) - Cylinder A01ch50eb
• 2001 SPORTSMAN 500 HO (A01CH50AK) - Cylinder A01ch50eb
• 2001 SPORTSMAN 500 RSE HO (A01CH50AJ) - Cylinder A01ch50eb
• 2001 SPORTSMAN 6X6 (A01CL50AA) - Cylinder
• 2001 WORKER 500 (A01CH50EB) - Cylinder
• 2002 500 MAGNUM VL HDS (A02CD50FB) - Cylinder A02cd50aa/Ab/Fb
• 2002 ATV PRO 500 4X4 PPS (C02CD50AC) - Cylinder
• 2002 INT'L BIG BOSS 6X6 (A02CL50DA) - Cylinder A02cl50aa/Da
• 2002 LUH 6X6 PPS (C02CL50AB) - Cylinder
• 2002 MAGNUM 500 (A02CD50AA) - Cylinder /Ab/Fb
• 2002 MAGNUM 500 2X4 HDS (A02CB50FC) - Cylinder
• 2002 MAGNUM 500 RMK (A02CD50AB) - Cylinder A02cd50aa/Ab/Fb
• 2002 SCRAMBLER 500 2X4 (A02BA50AA) - Cylinder /Ab
• 2002 SCRAMBLER 500 2X4 (A02BA50AB) - Cylinder A02ba50aa/Ab
• 2002 SCRAMBLER 500 4X4 (A02BG50AA) - Cylinder /Ac
• 2002 SCRAMBLER 500 4X4 FREEDOM (A02BG50AC) - Cylinder A02bg50aa/Ac
• 2002 SPORTSMAN 500 ALL OPTIONS (A02CH50) - Cylinder All Options
• 2002 SPORTSMAN 6X6 (A02CL50AA) - Cylinder /Da
• 2003 500 MAGNUM 4X4 HDS (A03CD50FB) - Cylinder
• 2003 SCRAMBLER 500 4X4 (A03BG50AA) - Cylinder
• 2003 SPORTSMAN 500 HO (A03CH50AA/AB/AC/AD/AE/AH/AJ) - Cylinder
• 2003 SPORTSMAN 6X6 (A03CL50AA) - Cylinder
• 2004 A04CH50AA SPORTSMAN 500 (A04CH50AA/AC/AE/AG) - Cylinder
• SERIES 10 PTV 4X4 (C10CD50AA) - Cylinder
• SERIES 10 PTV 6X6 (C10CL50AA) - Cylinder
• SERIES 10 RANGER (A10RD50AA) - Cylinder
• SERIES 10 RANGER 500 6X6 (A10RF50AB) - Cylinder
• SERIES 10 UTV 4X4 (C10RD50AA) - Cylinder
• SERIES 11 RANGER (A11RB42AA/A11RD50AA/AB/A11RF50AA) - Cylinder
• SERIES 11 UTV 2X4/4X4/6X6 (C11RB42AA/C11RD50AA/AB/C11RF50AA) - Cylinder
